LBP4690TC | Built-in Temperature Control Sensor
Types：1350KV、1200KV、900KV
Product Details
LBP4690TC Series | Built-in Temperature Control Sensor (Diam.×Length:Φ46.0mm×90.0mm) | ||||||||
Model | KV (RPM/Volt) | Max Amps | Max Voltage | Resistance (Ω) | No-load Current（11.1V） | Length of extend Shaft | Shaft Diameter (mm) | Weight |
LBP4690TC-2Y | 1350 | 125A | 25V | 0.0055 | 3.9A | 22mm | Φ5.0 | 650g |
LBP4690TC-4D | 1200 | 120A | 30V | 0.0071 | 3.3A | 22mm | Φ5.0 | 650g |
LBP4690TC-3Y | 900 | 100A | 36V | 0.0125 | 2.5A | 22mm | Φ5.0 | 650g |
